| Application | centre hinge for AVENTOS bi-fold lift systems |
|---|
| Arm Finish | Nickel plated |
|---|
| Boss Assembly | screw-on |
|---|
| Boss Depth | 12.5 |
|---|
| Boss Drilling Depth | 12.6 |
|---|
| Boss Finish | Nickel plated |
|---|
| Closing Mechanism | unsprung |
|---|
| Depth Adjustment | + 1.5/- 3mm |
|---|
| Diametre Hinge Boss Drilling | 35 |
|---|
| Door Material | Wood |
|---|
| Ean_Number | 9002617769012 |
|---|
| Item Package | 2 per set(2 CLIP centre hinges, 2 CLIP 120° hinges, 6 MPL) |
|---|
| Maximum Drilling Distance | 6 |
|---|
| Minimum Drilling Distance | 3 |
|---|
| Mounting Plate System | CLIP |
|---|
| Opening angle | 134 |
|---|
| Packaging | printed bag and carton |
|---|
| Side Adjustment | +/- 2 mm |
|---|
| Boss Adjustment | none |
|---|
| Boss Material | Zinc boss |
|---|
| Cover Cap Type | 90M2503 |
|---|
| Dampening | None |
|---|
| Fixing | for screwing on with chipboard screws |
|---|
| Type Of Depth Adjustment | convenient with spiral screw |
|---|
| Finish | Nickel plated |
|---|
| Type | AVENTOS HF |
|---|
| Product Combination | loose mounting plate |
|---|
CLIP top centre hinge for AVENTOS bi-fold lift systems 78Z5500T12
Opening angle: 134°
Boss assembly: screw-on
Boss material: Zinc boss
Closing mechanism: unsprung
Side adjustment: +/- 2 mm
Depth adjustment: + 1.5/- 3mm, convenient with spiral screw
