| Adjustment facility | Two-way adjustment:Vertical adjustment: 0-18 mm (Vertical adjustments through front gear cross socket interconnected to the vertical bolt, which reduces the cabinet adjustment effort)Horizont |
|---|---|
| Application | For hanging wall units |
| Installation | Dowels/Screw mounting:Slots into side cabinet by making four face borings and secured in position by rotating the locking pin with ridges 180°A 3.5 x 20 mm lateral wood screw permanently secu |
| Load bearing capacity | 130 kg per pair (Load carrying capacity applies to 2 cabinet hangers bearing an evenly distributed load in accordance with regulation DIN 68840) |
| Material | Steel |
|---|---|
| Note | Cabinet hangers should only be adjusted with a hand tool and not a power tool |
| Order reference | Wall plates and cover caps must be ordered separately |
